| Optional Accessory | Ref. | Description | Factory Fit Only |
|---|
 | Salt Solution Resevoir (80 Litres) | ACC59/1 | An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 460mm/18″ (w) x 620 mm/24″ (d) x 675mm/26″ (h)
| |
 | Salt Solution Reservoir (115 Litres) | ACC59/5 | A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h)
| |
 | Salt Solution Resevoir (160 Litres) | ACC59/9 | A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 840mm (w) x 500mm (d) x 790mm (h)
| |
 | Extra Heater Mats | ACC03 | Wrap around heater mats fitted to the sides of the chamber to allow the chamber to maintain temperatures of 60 Degrees Celsius during the salt spray phase, These extra heaters can be fitted to Salt Spray 450L and above, they are not available on CCT or Atmosfär range as these chambers already have them fitted as standard. *Exact part number dependent on chamber size.
|
|
 | Air Compressor (large) | ACC04/2 | A large free standing compressor, to provide a continuous supply of clean, dry and oil free compressed air, to enable the chamber to function without requiring connection to a local compressed air supply.
Electrical supply: 220-240VAC single phase, 50Hz
Output : 300 l/min displaced
Free Air Delivery (FAD) @ 6 Bar : 179 l/min
Max pressure: 8 Bar
Air receiver: 59 litres
Noise output: 74dB (A) measured at a distance of 1m
| |
 | Guardian Angel System - Standard LED Version | ACC05/1 | Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status.
Only available for Premium chambers (iP designations)
|
|
| Guardian Angel System - LED Version, with USB Connectivity | ACC05/2 | Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status, with USB connectivity for remote monitoring.
Only available for Premium chambers (iP designations)
|
|
| Guardian Angel System - LED Version, with Ethernet Connectivity | ACC05/3 | Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status, with Ethernet connectivity for remote monitoring.
Only available for Premium chambers (iP designations)
|
|
| Guardian Angel System - USB add on only | ACC05/4 | Retrofit add on for Guardian Angel, allows addition of USB connectivity for remote monitoring.
Only available for Premium chambers (iP designations)
| |
| Guardian Angel System - Ethernet add on only | ACC05/5 | Retrofit add on for Guardian Angel, allows addition of Ethernet connectivity for remote monitoring. Only available for Premium chambers (iP designations)
| |
 | Water Deioniser System (Small) | ACC06/1 | To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed.
Requires connection to a continuous mains water supply of maximum pressure 5.0 bar.
This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
| |
| Water Deioniser System (Medium) | ACC06/2 | To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed.
Requires connection to a continuous mains water supply of maximum pressure 5.0 bar.
This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
| |
| Water Deioniser System (Large) | ACC06/3 | To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed.
Requires connection to a continuous mains water supply of maximum pressure 5.0 bar.
This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
| |
 | 35mm Entry Port | ACC10/1 | Sealable chamber entry port of 35mm (1.27″) through the chamber’s left hand wall to enable the connection of external monitoring/driving equipment.
Note: not suitable for use with option ACC46.
|
|
| 110mm Entry Port | ACC10/2 | Sealable chamber entry port of 110mm (4.33″) through the chamber’s left hand wall to enable the connection of external monitoring/driving equipment.
Note: not suitable for use with option ACC46 or 120Ltr chambers
|
|
 | Hand-held salinity refractometer | ACC100 | A salinity refractometer optimized to give a direct reading of percentage sodium chloride in the range 0 to 28%, with automatic temperature compensation.
A single drop of the salt solution to be measured is placed on the viewing window, using the pipette supplied, and its salinity read against a high contrast scale, graduated in % sodium chloride, to give an accurate reading.
| |
 | Salt Solution Consumption Sensor | ACC102 | Electronic liquid flow sensor mounted inside the chamber and sensor situated in-line between the salt solution reservoir and the salt spray atomizer. The sensor measures the flow of salt solution from the reservoir to the atomizer. The output from the is displayed digitally at the chamber display as instantaneous consumption in ml per min and total consumption in ml.
Designed for use where a high salt solution flow rate is required and where that flow rate should be displayed electronically, such as Renault D17 2028. This has collection rates that equate to 4-6ml/80cm²/hr. This system may not work effectively at collection rates below this.
Only available for Premium chambers (iP designations).
|
|
 | Fallout Measuring Kit | ACC108 | Comprises of 4 x 100ml measuring cylinders and 4 x 100mm funnels, for manually collecting and measuring salt spray fall-out inside a chamber, during salt spray testing.
| |
 | Hand held pH meter | ACC11 | Digital pH meter, for measuring the pH of salt solution fallout over range 0-14 pH with a resolution of 0.01 pH. Supplied complete with buffers for calibration.
| |
 | Vertically Operating Canopy | ACC110 | Special design of canopy to allow it to open to a vertical position to enable access from above (e.g. by hoist) for large and/or heavy test samples.
*Exact part number dependent on chamber size.
|
|
 | 12 Month Consumables Kit for Cyclic Chambers | ACC57/2 | A kit of consumables sufficient for operating an Ascott Atmosfär, Kesternich, Cyclic or Salt Spray Premium chamber for up to 1 year.
Includes Salt Filters for Atomiser, Silicone tubing, Humidity Prove Filter Cap with O Ring & Air Filter
Note: A consumables spares kit is supplied as standard with every new chamber.
| |
 | 36 Month Servive & Spares Kit | ACC12/2 | An initial kit of spare parts for servicing and maintaining a chamber for up to 3 years from its first use.
| |
 | 72 Month Service & Spares Kit | ACC12/3 | A comprehensive kit for servicing and maintaining a chamber for up to 6 years from its first use, or its last service.
| |
 | Data Logging Software | ACC121 | This software allows logging of chamber variables and editing of chamber programs. It is uses a graphics based display which mimics and improves on the chamber interface. It can be loaded on Workstations or Laptops with Operating systems of Windows 10, Windows 8 Professional, Windows 7 Professional, Windows 2000 (SP4+), Windows XP Professional (SP3+). It also requires the following minimum hardware requirements – 1 GHz Processor minimum Processor, 256 MB RAM, video 1280 x 1024 (high colour 16 bit) and it is advised 2GB Hard Disk Space for data. The software communicates via an Ethernet network adaptor from chamber to PC / Laptop. The Workstation / Laptop also require a USB port to load the software and to accommodate the Dongle that is needed to run this software. Network must also be suitable as it will only work across a network on Class C subnet masks/ IP addresses – please liaise with your IT departments to confirm this or contact Ascott for further information.
Only available for Premium chambers (iP designations).
| |
 | Mesh Racking | ACC15 | Mesh type racking with an aperture of 30mm for testing small component parts. Locates on either the upper or lower level supports provided as standard inside the chamber, and removable if required. This product is available in a variety of sizes to suit different capacity chambers.
| |
 | Slotted Sample Racks | ACC16 | Removable slotted type sample rack for testing panels/coupons. Each slot is 3mm/1/8” wide and angled at 15 degrees from vertical. Such racks are supplied as standard, unless otherwise specified. Wider slots and/or different angles are available on request.
*Exact part number dependent on chamber size.
| |
 | General Motors Test Plate Kit | ACC16/6 | A kit of 10 specially designed Polycarbonate test plate holders and nylon fixings, as pictured, for mounting General Motors test plates in accordance with the requirements of GMW14872 – in an existing Ascott slotted sample rack, ref ACC16.
| |
 | Variable Sample Racks | ACC14 | Slotted sample racks for testing coupons on which the slot width and slot angle can be varied.
| |
 | Rod Sample Racks | ACC17 | Removable rod type sample rack for suspending small test samples hung beneath, or for supporting larger test samples placed on top of these racks.
*Exact part number dependent on chamber size.
| |
 | Spiked Sample Racks | ACC18 | Removable spiked type sample rack for suspending test samples from the 10mm/0.4″ diameter x 55mm/2″ long spikes, equally spaced, and protruding from opposite sides.
*Exact part number dependent on chamber size.
| |
 | Reinforced False Floor | ACC19 | Removable reinforced false floor, providing a horizontal platform over the chamber base for supporting large/heavy test samples.
*Exact part number dependent on chamber size.
| |
 | Waste Water Trough & Pump | ACC20 | Where a floor level drain connection is unavailable this option provides a holding tank into which the chamber drain outlet is terminated. When full, waste water is automatically pumped to an existing remote drain/effluent tank, up to 10m/32ft horizontally & 3m/10ft vertically from the chamber.
Note: not suitable for use with option ACC46.
|
|
 | Trolley | ACC24 | Converts the bench standing 120 Ltr size chamber to floor standing. Mounted on lockable castors. There is space underneath for one additional reservoir (separate option ref: ACC59).
| |
 | Interior Lighting | ACC26 | Illuminates the chamber interior when a control panel push-button is pressed.
*Exact part number dependent on chamber size.
|
|
 | Hand Held Temperature & Humidity Probe | ACC28 | Precision hand-held thermo-hygrometer for independently checking the chamber temperature and humidity. Includes a special salt resistant measuring probe mounted on an extension cable. Range: -40 to +85°C & 0 to 100%RH.
Requires any size entry port (see option ACC10) to access the chamber interior.
| |
 | 110V Transformer | ACC33 | Transformer to convert chambers to 110 Volts.
*Exact part number dependent on chamber size.
Note: only needed for SiS chambers.
|
|
 | Re-transmission of Temperature & Humidity | ACC36 | Re-transmission of chamber temp & humidity as 2 x 0-10VDC signals via externally mounted socket. For remote data logging. |
|
 | SO2 Gas Dosing | ACC46 | Designed to meet the requirements of ASTM G85 annex A4, this optional accessory comprises of a chamber mounted dispersion tube, through which SO2 gas is introduced, at a user adjustable rate and for a programmable duration.
*Exact part number dependent on chamber size.
Only available for Premium chambers (iP designations).
Notes.
The provision of the SO2 gas cylinder and connector are the users responsibility and are not included as part of this option.
The ACC46 is not suitable for use with options: ACC10, ACC34/INTERFACE, ACC92.
|
|
 | Temperature data logger | ACC50 | A battery powered, chamber mounted data logger and temperature sensor. Continuously records the chamber air temperature (°C). Logs can be downloaded to a computer running appropriate software (provided).
|
|
 | Chamber Raising Kit | ACC56 | Set of 4 adjustable height legs that allow the chamber to be raised to operate with high level drains.
| |
 | Manual filling air saturator | ACC66 | Enables the air saturator to be manually filled and periodically topped up with water by hand as an alternative to the automatic fill and top up provided as standard. Adds 75mm/3” to external chamber width.
|
|
| 80L Salt solution reservoir fitted with low level alarm | ACC59/3 | An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h)
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
|
|
 | Window insulated cover | ACC82 | Comprises of an insulated cover, which is specially shaped to match the window aperture. This will reduce the amount of condensation that can form on the inside of the window during testing and will also improve thermal efficiency.
*Exact part number dependent on chamber size.
| |
 | Exhaust salt scrubber (without circulation Pump) | ACC92/1 | Removes highly corrosive salt fog from the chamber exhaust where it is not convenient or possible to vent to the outside of the building. Removes salt through condensation and by spraying with water.
Note: not suitable for use with option ACC46.
| |
 | Exhaust salt scrubber (with circulation Pump) | ACC92/3 | Removes highly corrosive salt fog from the chamber exhaust where it is not convenient or possible to vent to the outside of the building. Removes salt through condensation and by spraying with water.
Note: not suitable for use with option ACC46.
| |
 | Compressed air coupling | ACC94 | A control panel mounted, quick release coupling to facilitate the connection of a third-party air pressure gauge (not supplied) for checking/calibrating the chamber’s own air pressure gauge.
|
|
 | 80 Litre (21 US gal) capacity salt solution reservoir fitted with Air agitation | ACC59/2 | An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h)
Fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
|
|
 | Atomiser Airflow Optimiser | ACC106 | An anemometer for measuring airflow and a mounting for this which positions it at a fixed distance from the end of the salt spray atomiser. This allows the airflow to be measured and if necessary adjusted. Consistent airflow at the atomiser can be a significant factor in obtaining good salt spray fall-out homogeneity, which is particularly important for some salt spray tests such as Renault ECC-1.
| |
 | 80L Salt solution reservoir fitted with Air Agitation and low level alarm | ACC59/4 | An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h)
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
|
|
| Salt Solution Reservoir (115 Litres) fitted with Air Agitation | ACC59/6 | A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h)
Fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
|
|
| Salt Solution Reservoir (115 Litres) fitted with Low Level Alarm | ACC59/7 | A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h)
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
|
|
| Salt Solution Reservoir (115 Litres) fitted with Air Agitation & Low Level Alarm | ACC59/8 | A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h)
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
|
|
 | Salt Solution Reservoir (160 Litres) with Air Agitation | ACC59/10 | A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 840mm (w) x 500mm (d) x 790mm (h)
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
|
|
| Salt Solution Reservoir (160 Litres) with Low level Alarm | ACC59/11 | A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 840mm (w) x 500mm (d) x 790mm (h)
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
|
|
| Salt Solution Reservoir (160 Litres) with Air Agitation and Low level Alarm | ACC59/12 | A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 840mm (w) x 500mm (d) x 790mm (h)
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
|
|
 | Salt Solution Reservoir (90 Litres) | ACC59/13 | A 90 Litre (23US gal) capacity external salt solution reservoir & removable lid for ease of filling and cleaning. Graduated scale in litres. Can be mobile and mounted on castors for mobility when purchased with ACC59/15 Salt Solution Reservoir Dolly.
External Dimensions: 540mm/21″ x 635mm /25″ width x height
| |
| Salt Solution Reservoir (73 Litres) | ACC59/14 | A 73Litre (19 US gal) capacity External salt solution reservoir & lid for ease of filling and cleaning. Graduated scale in litres. Can be mobile and mounted on castors for mobility when purchased with ACC59/15 Salt Soution Reservoir Dolly.
External Dimensions: 425mm Dia x 630mm (h)
| |
 | Salt Solution Reservoir (73-90L) Dolly | ACC59/15 | A Dolly for 73Litre (19 US gal) and 90L (23 US gal) External salt solution reservoir & lid for mobility. | |
| 12 Month Consumables Kit for Salt Spray Chambers | ACC57/1 | ACC57/1 is a kit of consumables sufficient for operating a Salt Spray chamber for up to 1 year.
Includes Salt Filters for Atomiser, Silicone tubing, & Air Filter
Note: this consumables spares kit is supplied as standard with every new Salt Spray chamber.
This item can be purchased online here
| |
| S120IS Installation Kit | ACC58/1 | An Installation kit for S120iS Chambers to help you connect your chamber to your existing utilities.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting. | |
| S120IP Installation Kit | ACC58/2 | A Handy Installation kit for S120iP Chamber to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
| S450IS Installation Kit | ACC58/3 | A Handy Installation kit for S450iS Chambers to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
| S450IP Installation Kit | ACC58/4 | A Handy Installation kit for S450iP Chambers to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
| S1000/1300IS Installation Kit | ACC58/6 | A Handy Installation kit for S1000/1300iS Chambers to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
| S1000/1300iP Installation Kit | ACC58/7 | A Handy Installation kit for S1000/1300iP Chambers to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
| S2000/2600iS Installation Kit | ACC58/9 | A Handy Installation kit for S2000/2600iS Chamber to help you connect your chamber to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting
| |
| S2000/2600iP Installation Kit | ACC58/10 | A Handy Installation kit for S2000/2600iP Chambers to help you connect your equipment to your services and exhaust.
Saves you time resourcing them locally and ensuring you get everything you will need.
Comprising of:
3m of 3/4″ Drain Pipe inc couplers and elbows
3m of 2″ Exhaust Pipework inc Couplers and Elbows
6m of 13mm Braided hose inc Clips for Air and Water connections
1/2″ Hosetail
Coupler-1/4″ Male-8mm to allow a push fitting.
(Items can be purchased separately too upon request).
| |
 | CR4 Grade Steel Corrosion Test Panels for ISO 9227 & VDA 233-102 | ACC131 | Ascott CR4 Test Panels are used to check the reproducibility and repeatability of the test results for Salt Spray or Cyclic Corrosion Test Chambers being being used to run ISO 9227 or VDA 233-102
| |
 | Two Button Canopy Control | ACC07 | Two button canopy operation ensures that the user must stand to the side of the chamber and use both hands in order to operate the pneumatically actuated canopy
|
|
 | Test Plate to hold small items/fasteners | ACC43 | A polycarbonate test plate holder pre-drilled with 7 holes (3 x 6mm, 2 x 5mm, 2 x 4mm) which are fitted with the nuts and bolts:
3 of them with fitted with an M6 x 25 nylon nut and bolt
2 of them with fitted with an M5 x 20 nylon nut and bolt
2 of them with fitted with an M4 x 25 nylon nut and bolt
When loaded with samples the plate slots into the standard slotted sample racks (Ref ACC16)
The plate can be used in different ways, if the nuts and bolts are removed the holes can be used to suspend samples directly (as long as the samples do not fall through the hole), or small samples with a through hole (nuts, washers etc.) can be suspended on the bolts.
| |
 | Sikkens® Scratch Tool | ACC49 | This scratching tool is specially designed to perform scribes on coated steel panels or test substrates prior to salt spray testing for example as described in ISO 9227 & ISO 12944-6
As standard, the scratch tool is supplied with 3 tungsten carbide cutting blades:
1 blade @ 0.5mm thick, the Daimler Chrysler version
1 blade @ 1mm thick, the original Sikkens® version
1 blade @ 2mm thick, requirement for 2018 update of ISO 12944-6
The blade is positioned by an adjustable guide block to assist cutting a straight line.
The guide block can be easily adjusted using the Allen keys provided. The tool features a soft grip ergonomically designed handle for ease of use and is supplied in a carry case.
| |
| Salt Solution Reservoir (227 Litres) | ACC59/16 | A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 830mm x 640mm x 740mm
| |
| Salt Solution Reservoir (227 Litres) fitted with Air Agitation | ACC59/17 | A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 830mm x 640mm x 740mm
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply. | |
| Salt Solution Reservoir (227 Litres) fitted with Low Level Alarm | ACC59/18 | A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 830mm x 640mm x 740mm
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop. | |
| Salt Solution Reservoir (227 Litres) fitted with Air Agitation & Low Level Alarm | ACC59/19 | A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility.
External Dimensions: 830mm x 640mm x 740mm
Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir.
Note: requires connection to a compressed air supply.
Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
| |
 | Increased salt spray volume | ACC134 | This accessory is designed in accordance with JSS 55555, which requires the quantity of salt solution sprayed per
hour to be approx. 1% of the volume of the chamber, for example 4.5L p/h for a 450L chamber , 10L p/h for a 1000L
Chamber 20L p/h for a 2000L Chamber and so on.
This is achieved by fitting additional atomisers to the chamber.
|
|
 | Air Inlet Isolation Valve | ACC136 | Isolation valve added to the inlet of the compressed air line. This allows for the Ascott chamber to be isolated from the incoming air , when the same airline is used for multiple pieces of other equipment.
|
|
| Air Saturator Pressure Vent Solenoid valve | ACC137 | Solenoid valve fitted to the air saturator to vent the air pressure; this allows the air saturator to automatically refill
when the incoming water pressure is below the recommended 2.5 bar limit.
|
|
 | Analogue Air Pressure Gauge | ACC138 | Analogue Air Pressure gauge, surface mounted on the front of the chamber, to see immediately the incoming air pressure. This is in addition to the digital air pressure gauge on the chambers control panel. If a chamber has more than 1 atomiser, the analogue gauge is supplied as standard.
Note: ACC138 is already fitted as standard with ACC01, ACC134 & ACC25 accessories, and fitted to all Atmosfar Premium Chamber as standard.
|
|
 | USB Logging port for IS/Alpha+ chambers | ACC139 | A USB logging port surface mounted on the chamber, allowing the customer to download set and process values
for the chamber temperature and chamber air saturator, into a csv. file into excel.
|
|
 | Mass Loss Coupons for GMW14872 & GM9540P | ACC135 | These panels are supplied in a Pack of 20, protectively wrapped to eliminate environmental contamination.
With a 1/4″ / 6.35mm centre hole to allow for secure bracketing
Heavy Oil Mass Loss Coupons that are fully compliant with the requirements of GMW14872 & GM9540P , Originally developed by General Motors these standards have gained popularity for corrosion tests within the automotive industry and have also become the preferred corrosion test of the US Navy.
| |
